Hydraulic Hose Wrapping Tshuab
Lub GW series hydraulic hose wrapping tshuab yog tshwj xeeb yog tsim los rau kev cia siab nruj thiab kaw cov kev xav tau kev pab rau dej hose, yeeb nkab coils, thiab lwm yam khoom coiled horizontally. Cov ntaub qhwv hose coils zoo kawg nkaus ntim thiab zoo nkaus li tidy thiab zoo nkauj rau cia, kev thauj mus los thiab kev ua lag luam. Cov lag luam yooj yim, qis zog thiab cov khoom siv, tab sis nrog cov neeg ua hauj lwm siab thiab cov nqi zog me ntsis.
Hauj lwm lawm
HYDRAULIC HOSE WRAPPING TSHUAB
Lub GW series hydraulic hose wrapping tshuab yog tshwj xeeb yog tsim los rau kev cia siab nruj thiab kaw cov kev xav tau kev pab rau dej hose, yeeb nkab coils, thiab lwm yam khoom coiled horizontally. Cov ntaub qhwv hose coils zoo kawg nkaus ntim thiab zoo nkaus li tidy thiab zoo nkauj rau cia, kev thauj mus los thiab kev ua lag luam. Cov lag luam yooj yim, qis zog thiab cov khoom siv, tab sis nrog cov neeg ua hauj lwm siab thiab cov nqi zog me ntsis.
YAM NTXIV:
* Lub hose packing tshuab yog nyob rau hauv kab rov tav qauv nrog ib lub rooj ua hauj lwm yooj yim rau phau ntawv tuav.
* Haum rau pob teeb pob coils uas yooj yim rau thauj khoom thiab thau tawm los ntawm phau ntawv.
* Overlapping tus nqi thiab zaj duab xis tension tau muab kho raws li qhov xav tau.
* Xaiv cov khoom sib txawv tau xaiv.
* Qhov kev qhia qhia teeb liab thaum pom teeb meem tshwm sim.
* Cov kab tawb uas muaj ntaub qhwv ntsej muaj ntaub qhwv nrog polyurethane los tiv thaiv cov khoom nto.
* Lub laj kab zoo rau kev xa khoom kom ua haujlwm zoo.
* Tsis siv neeg cov khoom noj thiab txiav yog xaiv.
* Lub tshuab tshuab tseem ceeb yuav tsim tau yooj yim rau kev tsav tsheb yooj yim ntawm cov coils hnyav.
* Conveyors yuav tsum tau nruab rau kev siv khiav lag luam.
MAIN PARAMETERS:
KHOOM | GW200 | GW300 |
Coil qhov siab | ≤ 200mm | ≤ 300 mm |
Coil OD | 300-500 hli | 300-600 hli |
Coil ID | ≥200mm | ≥250 hli |
Nplhaib ceev | Txog 20-90r / min | Txog 20-90r / min |
Overlap piv | 20% -90% kho tau | 20% -90% kho tau |
Khoom siv | Woven yas suab xev / ncab zaj duab xis / ntawv tso cai ntawv & lwm yam. W: 100 hli OD: ≤ 300 hli ID: 55mm | Woven yas suab xev / ncab zaj duab xis / ntawv tso cai ntawv & lwm yam. W: 100 hli OD: ≤ 300 hli ID: 55mm |
Tsim tawm | Txog 1.0kw | Txog 1.5kw |
Fais fab tuag voltage | 380V / 50Hz / 3 theem | 380V / 50Hz / 3 theem |
Synchronous wrapping system | Yeem xaiv | Yeem xaiv |
Tsis siv neeg kho tshuab tes | Yeem xaiv | Yeem xaiv |
Lus Cim: cov ntaub ntawv tsuas yog siv rau, lub tshuab yuav ua kev cai tsim raws li ib qho khoom tshwj xeeb.
TAW QHIA RAU LUB OPERATING PANEL SWITCH:
FAIS: Lub zog ntawm lub tshuab fais fab uas siv los txuas lossis kaw lub tshuab fais fab.
KEV QHIA TXOG KEV THAUM MUAJ XWM CEEV: Qhov kev hloov tswj uas siv los tswj tus ntu. Nias kom kaw lub tshuab thaum muaj xwm ceev.
Pib: Nias lub pob kom ua lub suab nrov ua haujlwm.
NRES: Nias lub pob kom lub suab nrov nres
RING RESET: Rov ua dua lub nplhaib, ua rau & tawm ntawm tus kwv yoojyim.
COV MENYUAM (FWD / REV): Siv cov menyuam yaus hauv qab xaim moos los yog sijhawm teem rau thaum lub nplhaib pib khiav.
RING JOG: Nias lub pob, lub nplhaib qeeb qeeb, thiab yuav nres thaum looses khawm. Siv los xyuas seb lub nplhaib puas dhau ntawm lub chaw ua haujlwm.
SIJ HAWM: txiav lub sijhawm teem. Cov khoom ntim yuav raug txiav tom qab lub sijhawm teem. Kho lub sijhawm raws li kev xav tau.
TOM QAB-MUAG KHOOM
12 lub hlis warranty rau tag nrho cov tshuab
DAWB spare ntawm lub tshuab
Cov lus teb rau kev kho sai ua ntej 24 xuab moos thaum txais daim ntawv thov
10 xyoo warranty rau lub npe koob meej
Tuav tsev kho mob muaj nyob yog tias tsim nyog
Kev hloov tshiab lub tshuab hloov rau cov teeb meem tsis tshua muaj teeb meem
CERTIFICATE
CE Pom Zoo
IEC PROTECTION
IP54
