Stainless Hlau Wrapping Tshuab
Lub tshuab stainless hlau wrapping yog ib qho automatic packing kua tshwj xeeb tshaj yog rau niaj hnub steel manufacturers, uas yog tseem zoo muaj feem xyuam rau txawv lub nplhaib ntawm cov khoom siv hlau steel coils, cov coils, yeeb nkab coils, tooj liab coils, thiab lwm yam. Lub tshuab yog tsim nrog loading trolley kev nyab xeeb tuav thiab kev thauj khoom ntawm hnyav hlau coils. Cov ntaub qhwv steel hlau yog zoo-tiv thaiv & kaw & zoo nkauj & zoo li tidier nrog cov dej tsis muaj dej, hmoov txhaws pov thawj, muaj puavpheej pov thawj, hnav cov ntaub ntawv pov thawj, kev tiv thaiv kev laus.
Hauj lwm lawm
STAINLESS STEEL WRAPPING TSHUAB
TSHUAB KEV THOV:
Lub tshuab stainless hlau wrapping yog ib qho automatic packing kua tshwj xeeb tshaj yog rau niaj hnub steel manufacturers, uas yog tseem zoo muaj feem xyuam rau txawv lub nplhaib ntawm cov khoom siv hlau steel coils, cov coils, yeeb nkab coils, tooj liab coils, thiab lwm yam. Lub tshuab yog tsim nrog loading trolley kev nyab xeeb tuav thiab kev thauj khoom ntawm hnyav hlau coils. Cov ntaub qhwv steel hlau yog zoo-tiv thaiv & kaw & zoo nkauj & zoo li tidier nrog cov dej tsis muaj dej, hmoov txhaws pov thawj, muaj puavpheej pov thawj, hnav cov ntaub ntawv pov thawj, kev tiv thaiv kev laus.
YAM NTXIV:
* Cov hom kev lag luam zoo siab tau siv rau cov khoom tseem ceeb ntawm cov hlau coil packing tshuab.
* Ob qho tib si nws pib thiab tsis siv neeg ua haujlwm hom kev lag luam.
* PLC qhov kev pab cuam thiab HMI rau kev khiav lag luam.
* Kev nyab xeeb thiab txhim khu kev qha trolley kom yooj yim rau khoom ntawm cov khoom.
* Kev tiv thaiv npog, pib mos thiab tso cai ua haujlwm kom ruaj ntseg.
* Txwv txoj kev hloov, cov ntsuas thiab qhov kev nyab xeeb rau kev lag luam kom ruaj ntseg.
* Kev tiv thaiv kev tiv thaiv rau cov hlau cov tshuab.
* Tig nplhaib qhov siab yuav muab kho rau cov hlau sib txawv lub dav hlau.
* Cov kev pabcuam uas muaj kev txhawb nqa los ntawm cov tsheb ua haujlwm rau kev tiv thaiv kev tiv thaiv.
* Cov ntaub ntim ntawv muab txiav yog txiav los ntawm qhov kev pab cuam raws li kev sib txawv coil.
* Txiag hluav taws xob tswj lub txee rau cov lag luam yooj yim, qhov ntsuas alarming tau thaum yuam kev lawm.
* Siv lub nplhaib thiab kev siv lub tshuab, ruaj khov thiab ruaj khov, ua haujlwm ntev hauv lub neej.
MAIN PARAMETERS:
Qauv | GD300 | GD600 | GD800 |
Coil dav | ≤ 300 | 150 hli-600 hli | 400mm-800 hli |
Coil OD | ≤1500 | 800mm-1600 hli | 1000 hli-1900 hli |
Coil ID | 508 / 610mm | 508mm / 610mm | 508mm / 610mm |
Coil hnyav | ≤2000Kg | 300kg-6000Kg | 1000Kg-12000kg |
Nplhaib ceev | Pom zoo. 20-90r / min | Pom zoo. 20-80r / min | Pom zoo. 20-60r / min |
Cov tub ceev xwm ceev | 5-8m / min | 5-8m / min | 5-8m / min |
Fais fab tso zis | Hais txog 4.0KW | Txog 7.5KW | Txog 10.5KW |
Lub hwj chim | AC / 380V / 50Hz | AC / 380V / 50Hz | AC / 380V / 50Hz |
Pa cua | 6-8kgf / cm 2 | 6-8kgf / cm 2 | 6-8kgf / cm 2 |
Cov khoom siv | Compound daim ntawv / VCI ntawv / Paj ntaub kab xev: dav: 80-100mm; ID: 55mm; OD≤500mm | Compound daim ntawv / VCI ntawv / Paj ntaub kab xev: dav: 80-100mm; ID: 55mm; OD≤500mm | Compound daim ntawv / VCI ntawv / Paj ntaub kab xev: dav: 80-100mm; ID: 55mm; OD≤500mm |
| Ncab zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli | Ncab zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli | Ncab zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli | |
Synchronous wrapping system | Yeem xaiv | Yeem xaiv | Yeem xaiv |
Automatic manipulator | Yeem xaiv | Yeem xaiv | Yeem xaiv |
Lus Cim: cov ntaub ntawv tsuas yog siv rau, lub tshuab yuav ua kev cai tsim raws li ib qho khoom tshwj xeeb.
NTXIV:
Tag nrho cov kev hloov & Kev Hloov Transformer, tswj kho vajtse yuav muab los ntawm JLPACK & yog muaj tsev nyob hauv vaj huam sib luag.
Txhua qhov thaiv kab nrog lub Push Button Stations, Terminal Boxes, & Hlawv Boxes.
Tag nrho cov Electrification nrog Field I / P Sensors, PRX, LS nrog Solenoids & lwm cov khoom siv tawm muaj nyob rau hauv kab.
Cov ntawv pov thawj Software rau PLC + HMI + DRIVE yuav muab rau.
LWM YAM NTSIAB LUS:
* Txhua lub lag luam & Kev Hloov Transformer, tswj kho vajtse yuav muab los ntawm JLPACK & yog muaj tsev nyob hauv vaj huam sib luag.
* Txhua qhov thaiv kab nrog lub Push Button Stations, Terminal Boxes, & Hlawv Boxes.
* Tag nrho Electrification nrog Field I / P Sensors, PRX, LS nrog Solenoids & lwm cov khoom siv tawm muaj nyob rau hauv kab.
