Tsis Siv Neeg Tyre Cov Tshuab

Shanghai Jinglin muaj ntau yam kev daws teeb meem rau kev lag luam kev lag luam. Qhov no GD300 tsis siv neeg tho packing tshuab yog muaj feem xyuam rau cov log tsheb ntau yam xws li lub tsheb log tsheb / tsheb log / tsheb tsheb / roj hmab log / log / tsheb tuam / tsheb kauj vab log thiab lwm yam. Lub cav ntim tshuab tuaj yeem tsim los ntawm cov khoom tis loj (ID, OD, dav) los xyuas kom cov log tsheb muaj qhov zoo tshaj plaws pob khoom. Qhov nplaim ntawm cov ntawv ntim cov khoom haum yog zoo, zoo & huv thiab tuaj yeem txhim khu koj cov khoom competitiveness.

Xa kev nug

Hauj lwm lawm

TSIS SIV NEEG LIS COV TSHUAB

KEV THOV:

INSTALLATION:

Lub tshuab tuaj yeem tso rau ntawm cov av hauv npoo av, thiab muab tso rau hauv cov av hauv av kom yooj yim khiav.

YAM NTXIV:

1. Lub tshuab nrog cov qauv yooj yooj yim, yooj yim rau kev khiav hauj lwm.

2. Tsis siv neeg tswj lub tshuab ntawm PLC.

3. Kev ruaj siab nruj tswj xyuas tau kom zoo rau kev ntim khoom.

4. Daim ntaub nplaum tshaj li ntawm cov tsev kawm ntawv qib siab yog kho tau los ntawm 10% -90%.

5. Lub nplhaib tig qhov siab tau kho, nplua rau log tsheb uas txawv ID thiab OD.

6. Cov caj pas npuaj npuaj los ntawm PU los tiv thaiv cov khoom zoo.

7. Peb lub yeeb yam qhia txog lub teeb lub tswb nrov thaum muaj qhov yuam kev.

8. Lub sij hawm ntim tuaj yeem teem rau ntawm lub vaj huam sib luag rau kev nres tsheb tsis siv neeg.

9. Tapping ntaus ntawv yog xaiv tau rau cov lus xaiv tau rau ntawm daim ntawv sau kab xev tib lub sijhawm.

MAIN PARAMETERS:

Qauv	GD300 ntsug
Log log	20mm-300 hli
Tyre OD	700mm-1400 hli
Log tsheb	≥300 hli
Log hnyav	30kg-100Kg
Nplhaib ceev	20-90r / min
Cov tub ceev xwm ceev	5-8m / min
Fais fab tso zis	Hais txog 2.0KW
Lub hwj chim	AC / 380V / 50Hz
Pa cua	6-8kgf / cm ²
Cov khoom siv	Ua ntaub ntawv / ntaub ntawv xov xwm: ntu: 80-100 hli; ID: 55mm; OD≤500mm
Cov khoom siv	Ncab zaj duab xis / PE zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli
Synchronous wrapping system	Yeem xaiv
Tsis siv neeg kho tshuab tes	Yeem xaiv
Logo taping system	Yeem xaiv

Lus Cim: cov ntaub ntawv tsuas yog siv rau, lub tshuab yuav ua kev cai tsim raws li ib qho khoom tshwj xeeb.

KEV TSIS TXAUS SIAB THIAB KEV PAB CUAM

1. Tus Neeg Muag Khoom:

(a) Cov khoom siv tau los ntawm Lub Chaw Muag khoom yuav tsum yog cov tshiab thiab tsim ntawm cov ntaub ntawv txaus thiab zoo, thiab tsis muaj qhov tsis xws luag.

(b) Cov Ntaub Ntawv Cov Ntaub Ntawv yuav tsum ua kom tiav, meej thiab muaj tseeb.

2. Lub caij nyoog ntawm kev tiv thaiv: 12 lub hlis ntawm hnub tim ntawm Txais:

(a). Nyob rau lub sij hawm, Tus Neeg Muab Kev Pab muab cov khoom hloov los yog kho ntawm qhov chaw tawg

dawb rau cov teeb meem no tsis yog tshwm sim los ntawm kev lag luam txawv txawv, kev tsis tsim nyog

Kev pabcuam / kho lossis siv cov khoom tsis muaj tseeb.

(b). Muab kev txhawb nqa thiab kev cob qhia los ntawm email, xov tooj, fax thiab lwm yam li ntawm 24 xuab moos thaum tau txais daim ntawv qhia tus neeg tuaj.

(c). Yog xav tau, nws muaj peev xwm xa tus kws kho tsheb mus tom qab kev pab. Cov nuj nqis ntawm tus kws kho tsheb

nrog rau kev sib tw thiab kev pabcuam yuav tsum tau txais los ntawm tus qhua tuaj noj mov.

3. Lub sijhawm ua haujlwm pabcuam thiab txhawb nqa.
