Hlau Tshuab Dhos Wrapping Tshuab

Cov hlau ntim wrapping tshuab yog nruab nrog txav loading trolley kom muaj kev nyab xeeb thiab kev yoojyim rau kev siv tes ua haujlwm thaum lub sijhawm ua haujlwm, lub tshuab siv dav siv rau sab nrauv ncab ntawm xaim hlau, copper coils, aluminium coils, steel coils, kab xev, kab xev yas, thev naus laus zis, thiab lwm yam, ua kom cov co tsis muaj dej, tsis muaj rustproof, plua plav, thiab zoo rau kev cia thiab kev thauj mus los.

Xa kev nug

Hauj lwm lawm

HLAU BUNDLE WRAPPING TSHUAB

TSHUAB KEV THOV:

INSTALLATION:

Lub tshuab yuav tsum tau muab tso rau hauv lub tiaj & lub zog hauv av, qhov chaw hauv av yuav tsum ntau tshaj 1 tuj / m ² .

YAM NTXIV:

1. Kev tsim tshwj xeeb ntawm kev sib tsoo trolley rau kev lag luam kev nyab xeeb thiab yooj yim dua.

2. Ntse ntse thiab ua haujlwm yooj yim. Tsuas yog yuav tsum teeb tsa OD, ID, thiab dav ntawm cov khoom siv coiled, lwm cov kev txwv yuav raug teev tseg;

3. Qhov siab tshaj plaws ntawm lub rooj tsav tsheb yuav raug kho rau OD & ID txawv;

4. Cov ntaub ntawv nrawm nrawm tau kho tau;

5. Synchronous wrapping yog muaj. Muab cov ntaub ntawv thev & pob yeeb yaj kiab tuaj txav rau hauv ib pob ntawv kom ua hauj lwm ntau dua;

6. Muaj ntau ntau ntawm cov ntaub qhwv cov khoom haum.

7. Nqa tshwj xeeb txiav khoom siv;

8. Cov neeg ua hauj lwm tes muaj nyob rau kev pub & txiav cov khoom ntim khoom;

9. Ntiv nplhaib pib thaum lub thawv ntim tiav, npaj rau lwm pob.

10. Polyurethane nplaum yog siv los qhwv cov caj dab kev tuav pov hwm thiab tiv thaiv cov thawv ntawv.

MAIN PARAMETERS:

Qauv	GD300	GD600
Hom	Trolley hom	Trolley hom
Yam khoom	Hlau coils / tooj liab coils / hlau coils / etc.	Hlau coils / tooj liab coils / hlau coils / etc.
Coil dav	≤ 300	≤600 hli
Coil OD	≤1500	≤ 1600 hli
Coil ID	508 / 610mm	508mm / 610mm
Coil hnyav	≤2000Kg	≤6000Kg
Nplhaib ceev	Pom zoo. 20-90r / min	Pom zoo. 20-80r / min
Cov tub ceev xwm ceev	5-8m / min	5-8m / min
Fais fab tso zis	Hais txog 3.0KW	Hais txog 4.5KW
Lub hwj chim	AC / 380V / 50Hz	AC / 380V / 50Hz
Pa cua	6-8kgf / cm ²	6-8kgf / cm ²
Cov khoom siv	Compound daim ntawv / VCI ntawv / Cov ntaub nplaum rau daim kab xev: 80-100mm; ID: 55mm; OD≤500mm	Compound daim ntawv / VCI ntawv / Paj ntaub kab xev: dav: 80-100mm; ID: 55mm; OD≤500mm
Cov khoom siv	Ncab zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli	Ncab zaj duab xis: dav: 80-100mm; ID: 50 hli; OD≤150 hli
Synchronous wrapping system	Yeem xaiv	Yeem xaiv
Automatic manipulator	Yeem xaiv	Yeem xaiv

Lus Cim: cov ntaub ntawv tsuas yog siv rau, lub tshuab yuav ua kev cai tsim raws li ib qho khoom tshwj xeeb.

KHOOM TXIM XWM TXAWV

Cov khoom siv hluav taws xob muaj nyob rau ntawm daim phiaj teeb phom hauv cov khoom kaw, kev tiv thaiv degree IP20, tsim hauv daim ntawv 1 raws li EN 60439-1. Txhua lub txee muaj ib daim ntawv cim npe ntawm lub qhov rooj nrog qhov chaw tsim nyog.

Rittal tus qauv hloov khoom siv.

Cov chaw hloov khoom siv yog nruab rau hauv lub txee hloov khoom.

Kev thauj lub txee system yuav muab sib cais rau hauv cov chav nyob shipping nrog ntau siab dav ntawm 3600 hli.

Lub subdivision ntawm cov khoom ntiag tug yog ua raws li lawv txoj haujlwm:

* Noj

* Tswj cov cim hluav taws xob, pab tsav tsheb

* Lub ntsiab tsav tsheb

* Tswj
